Features:
| Servo Model |
160SS |
| Recommended Application | 1/12 to 1/10 scale Surface |
| Operating Voltage | 4.8V - 7.4V |
| Operating Temperature | 14° to 140° F (-10 to +60° C) |
| Operating Speed @ 6.0V | 0.05/60° sec |
| Operating Speed @ 7.4V |
0.04/60° sec |
| Dynamic Torque @ 6.0V |
127 oz-in (9.1 kg-cm) |
| Dynamic Torque @ 7.4V |
152 oz-in (11 kg-cm) |
| Motor Type |
High Efficiency Coreless Motor |
| Output Shaft | 25 Tooth |
| Gears | Metal |
| Weight | 54.5g |
| Pulse/Frequency |
1520?s / 333hz |
| Dimensions | 39.5x20x30.3mm |
| Length (Bottom to Mount) |
19.10mm |
